MODEL | MANIPAV-3000 | MANIPAV-2000 |
Weight | 1.300 KG | 550 KG |
Power | LOMBARDINI (LDW 1003/B1) LIQUID COOLED,27hp,3cyl.EPA | HONDA IGX440 15Hp, Air cooled |
Fuel Capacity | 15L | 7L |
Control system | ELECTRIC/HIDRAULIC | ELECTRIC/HYDRAULIC |
Driver | 3 Hyraulic motor | 3 Hyraulic motor |
Vibration | VIBRATING BEAM 300cm VIBRATOR ELECTRIC 3000rpm | VIBRATING BEAM 250cm VIBRATOR ELECTRIC 3000rpm |
Fuel capacity | 95 L | 40 L |
Hydraulic cylinder laser | 48 cm HIGH | 30 c.m. HIGH |
Distance from the floor | 35 c.m. | 18 c.m. |
Dimention | ||
Long | 340 c.m. | 290 c.m. |
Width | 350 c.m. | 250 c.m. |
Height | 210 c.m. | 175 c.m. |
Production | 500 M2/H Aprox | 250 M2/H Aprox |
Laser control system | SPECTRA-TRIMBLE 1 CONTROL BOX 2 RECEIVERS LR-30 KIT CONECTION | SPECTRA-TRIMBLE 1 CONTROL BOX 2 RECEIVERS LR-30 KIT CONECTION |
