- The body of the silo is whirled and tapered on a dedicated cyclone to ensure a consistent and uniform round.
- Welds are welded on MIG - MAG welding machines with a team of skilled workers, ensuring the tight seal, durable.
- Silicon paint process ensures quality standard TCVN334-2005, paint 3 layers (1 anti-rust layer + 2 paint) with a total paint thickness of 90μm. Check the thickness of paint by specialized equipment imported from Europe.
- System: dust filter designed to ensure effective dust, friendly people and surrounding environment.
| SL-60 | SL-80 | SL-100 | SL-120 | SL-150 | SL-200 |
Storage capacity (m3 / ton) | 46/60 | 62/80 | 83/100 | 90/120 | 113/150 | 145/200 |
Diameter of silicon D (mm) | 2660 | 2830 | 3400 | 3400 | 3400 | 4700 |
Overall height H1 (mm) | 12873 | 14400 | 14876 | 15586 | 22000 | 16389 |
Heel height H2 (mm) | 4000 | 4000 | 4200 | 4200 | 4200 | 6594 |
Height of outlet mouth H3 (mm) | 2331 | 2250 | 2300 | 2300 | 2300 | 3534 |
Material | Ct3 | Ct3 | Ct3 | Ct3 | Ct3 | Ct3 |
Contact 0916 427 068 - 0902 686 002 - Mr.Dũng for advice and receive the best quotation.
