The Triple Roller pavers is a low cost concrete paving machine for concrete road projects with paving width from 2,5m to 11m. Triple Roller GT-serial can use for any slump, any depth of concrete. Powered by electric motor or Diesel engine with easy-to-operate control system.
MAIN SPECIFICATION
MODEL | GT 3500 | GT 4500 | GT 5500 | GT 7000 |
Paver width | 3.5 m | 4.5 m | 5.5 m | 7 m |
Working speed | 30m/h | 30m/h | 22m/h | 10m/h |
Moving speed | 10 m / min | 10 m / min | 10m/min | 6.5-8m/min |
Roller diameter | 219mm | 219mm | 219mm | 219mm |
Impact motor power | 5 HP | 5 HP | 7.5 HP | 7.5 HP |
Moving motor power | 3 HP | 5 HP | 5 HP | 7.5HP |
Weight | 1050 kg | 1260 kg | 1410 kg | 1800 kg |
